Technical information
Operation system: Embedded Linux OS
Online visitor: Support 4 visitors at the same time
Image sensor: 1/2.7inch 1080p Progressive Scan CMOS
Minimum Illumination: 0.5Lux (Color mode),0.1Lux (B&W mode)
Lens: 3.6mm @F2.5
View Angle: 102.4° (diagonal)
Night vision: Dual Filter,IR-Cut,6pcs 850nm Φ5mm IR LED,
IR irradiation distance: 10m
Encode format: H.264 main profile @levels:4.0/Motion-JPEG
Three Stream:
Main Stream:1080p(1920X1080)@15fps
Sub Stream:360p(640X360)@15fps
Third Stream:180p(320X180)@10fps
Bit Rate: 128~4096kbps
Maximum frame rate: 15fps
Image adjustment: Contrast, Brightness, Saturation, Hue
Audio Input: Built-in -38 dB microphone
Output: Built-in speaker(8Ω 1W)
Sampling frequency / width: 8KHz/16bit
Compression standard: ADPCM/32kbps
Ethernet: 10Base-T / 100Base-TX, RJ45 connector
Protocols: TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc
Wireless LAN: IEEE802.11b/g/n
Wireless LAN Frequency: 2.4~ 2.4835GHz
Wireless LAN security: 64/128-bit WEP/WPA-PSK /WPA2-PSK data encryption
Pan: 350°,tilt:90°(Privacy position is not included)
Preset position: PC APP:support 16 positions, phone APP:support 5 positions
Memory Socket: TF Push-push socket,Maximum support 128GB, Cloud Storage
Alarm Trigger: Motion detection
Rated voltage: DC 5V±5%
Power consumption: 2.4W(IR LED on), Maximum:5.25W(Pan&Tilt on)
Operating condition Temperature:-10~50?,humidity:<90%
Gross Weight: 210g
